Evaluate NeurEco Parametric Frequency Sweep model with the GUI

• Switch to the Evaluation tab



  Evaluate tab for Parametric Frequency Sweep

• Choose the file to evaluate in Evaluation files section:

  • If the file was supplied in Settings for Build, it is already listed in Evaluation files

  • To add a new file for evaluation, press + in Additional section of Evaluation files

  • For Evaluate, the output file is not required. When it is available, it can be provided for comparison purposes.

• Once the input file clicked (or a pair input/output), the results of Evaluate are displayed. Here inputs file inputs_test.npy was added and evaluated:



  Results of Evaluate for Parametric Frequency Sweep

• To save the results of evaluation into a CSV, NumPy or MAT-file (under development), click Export prediction.

  If the box Also export original files is checked, the input file or input/output files will be exported as well.

Note

By default, the evaluation is performed with the last model available in the checkpoint.

Use the checkpoint slider in the bottom to choose any other available model to Evaluate it.
